Emission Regulation – Tier 2 / Stage II
Model – Weichai WD10G240E201
Rated Power – 178 kW @ 2,200 rpm
Max Torque – 1000 N · m
Displacement – 9.726L
Number of Cylinders – 6
Aspiration – Turbocharged
Tipping Load – Full Turn – 137 kN
Bucket Breakout Force – 205 kN
Maximum Dump Angle at Full Height – 45°
Dump Clearance at Full Height Discharge – 3480 mm
Dump Reach at Full Height Discharge – 1300 mm
Maximum Hinge Pin Height – 4718 mm
Maximum Digging Depth, Bucket Level – 80 mm
Bucket Capacity – 4m³
Operating Weight – 22500kg
Transmission Type – Planetary, power shift
Torque Converter – Single stage, four elements
Maximum Travel Speed, fwd – 37 km/h
Maximum Travel Speed, rev – 16 km/h
Number of Speeds, fwd – 2
Number of Speeds, rev – 1
Differential Front Type –
Differential Rear Type –
Axle Oscillation – ±12°
Steering Configuration – Articulated
Steering System Pressure – 18 Mpa
Service Brake Type -Caliper disc brake
Service Brake Actuation – Air over Hydraulic
Parking Brake Type – Air brake
Parking Brake Actuation – Mechanica
Tire Size – 26.5-25
Accordion Content
Main Pump Type – Gear
Main Relief Pressure – 21 Mpa
Raise time – 5.3 S
Total Cycle Time – 9.97
Fuel Tank – 330 L
Hydraulic oil Tank – 255L
Engine Oil – 21 L
Axles, each – 41LX2
Transmission – 45 L
Antifreeze – 80 L
Length – 9320 mm
Width – 3080 mm
Height – 3570 mm
Wheelbase – 3500 mm
Wheel Tread – 2250 mm
Ground Clearance – 510 mm
Turn Angle, Either Side – 35°
Turning Radius, Outside of Tire – 6955 mm
Turning Radius, Center of Tire – 6675 mm
Turning Radius, Bucket Carry – 7686mm
