Make – Weichai Euro 2 Turbo charged Intercooled
Model Configuration – WP 10.290 E32
Max Power—Kw @ r/min – 2 /2200
Max Torque—N.m @ r/min – 1160/1200-1600
HP – 290
Cylinder – 6 Inline
Water Cooled – Yes
Direct Injection – Yes
Engine driven P.T.O – No
Displacement (l) – 9.726
Compression Ratio – 17:01
Service – Dual circuit air brakes
Emergency / Parking – Spring potential brake
Auxiliary – ABS & EVB
Size and ply rating – 14.00R20 incl spare wheel
Type – AR7/10DS-7/4.769
Suspension – Non-free standing stabilization leaf spring, hydraulic shock absorber
Type – HL7/015DS-13 – 4.769
Suspension – Stabilizator suspension, hydraulic shock absorber
Alternator – 70Amp
Starter Motor – 5.58kW
Batteries – 2 x 12V – 135AH
Gradeability @ GVM – 60% @ GVM
Max Geared Road Speed – 98km/h (Limited to 80km/h)
Final Drive Ratio – 4.769
Make / Type / Size – GFX 430mm single
Operation – Single dry frictional disc, diaphragm spring, pulling type
New Vehicle – 3 years / 300 000km (SA only)
Make/Model – 12JS160T
No of Gears – 12
Synchromesh or Constant Mesh – Synchromesh
Transfer Box – VG1400-3W (14 000 N.m)
P.T.O – No
Crawler
1st – 15.53
2nd – 12.08
3rd – 9.39
4th – 7.33
5th – 5.73
6th – 4.46
7th – 3.48
8th – 2.71
9th – 2.10
10th – 1.64
11th – 1.28
12th – 1.00
Reverse L – 14.86
Reverse H – 3.33
Overall Length (OL) – 8 390
Overall Width (OW) – 2 495
Overall Height (OH) – 3 200
Front Overhang (FOH) – 1 435
Rear Overhang (ROH) – 2 340
Wheel Base (WB) – 4 500
Bumper to Back of Cab (BBC) – 1 880
Cab to rear axle / unit (CA) – 4 060
Turning Radius (TR) – 9 000
Fuel Tank Capacity (FTC) – 400 LTR
Manufacturers Gross Vehicle Mass (GVM) – 17 000
Manufacturers Gross Combination Mass (GCM) – 34 000
Manufacturers Front Axle Mass (GA) – 7 500
Manufacturers Rear Axle Mass (GAU) – 13 000
Permissible Maximum Vehicle Mass (V) – 15 500 (Singles)
Permissible Maximum Front Axle Mass (AF) – 7 500
Permissible Maximum Rear Axle Mass (AR) – 8 000 (Singles)
Unladen Front Axle Mass (UF) – 4 740
Unladen Rear Axle Mass (UR) – 2 400
Total Unladen Mass (UT) – 7 140
Permissible Max Drawing Vehicle Mass (D/T) – 34 000
Hydraulic Tiltable Cab
