Make: Weichai Euro 2 Turbo charged Intercooled

Model Configuration: WP 10.340 E32

Max Power—Kw @ r/min: 250/2200

Max Torque—N.m @ r/min: 1350/1200-1600

HP: 340

Cylinder: 6 Inline

Water Cooled: Yes

Direct Injection: Yes

Engine Driven P.T.O Yes

Displacement (l): 9.726

Compression Ratio: 17:01

Service: Double circuit air brakes

Emergency / Parking: Spring potential brake

Auxiliary: ABS & EVB

Size and ply rating: 315/80R22.5 incl spare wheel

Type: VR4/01D-7.5

Suspension: Non-free standing stabilization leaf spring,
hydraulic shock absorber, transverse
stabilizer

Type: HD7/016DGS – HL7/015DS-13/4.796
Hub reduction axles

Suspension: Stabilizator suspension, 13 pcs leaf

spring (each 20mm

Alternator: 70Amp

Starter Motor: 5.58kW

Batteries: 2 x 12V – 120AH

Gradeability @ GVM: 30% @ GVM

Max Geared Road Speed: 90km/h (Limited to 80km/h)

Final Drive Ratio: 4.769

Make / Type / Size: GFX 430mm single

Operation: Single dry

New Vehicle: 3 years / 300 000km (SA only)

Make/Model: 12JS200T+QH50

No of Gears: 12

Synchromesh or Constant Mesh: Synchromesh

P.T.O: Yes

Overall Length (OL): 9 400

Overall Width (OW): 2 495

Overall Height (OH): 3 085

Front Overhang (FOH): 1 435

Rear Overhang (ROH): 1 350

Wheel Base (WB): 5 025

Bumper to Back of Cab (BBC): 2 215

Cab to rear axle / unit (CA): 5 040

Turning Radius (TR): 11 500

Fuel Tank Capacity (FTC): 400 LTR

Manufacturers Gross Vehicle Mass (GVM): 40 000

Manufacturers Gross Combination Mass (GCM): 75 000

Manufacturers Front Axle Mass (GA): 15 000

Manufacturers Rear Axle Mass (GAU): 26 000

Permissible Maximum Vehicle Mass (V): 31 650

Permissible Maximum Front Axle Mass (AF): 15 000

Permissible Maximum Rear Axle Mass (AR): 18 000

Unladen Front Axle Mass (UF): 5 880

Unladen Rear Axle Mass (UR): 4 260

Total Unladen Mass (UT): 10 140

Permissible Max Drawing Vehicle Mass (D/T): 60 000

Hydraulic Tiltable Cab
