Make – Weichai Euro 2 Turbo charged Intercooled
Model Configuration – WP 12.420 E32
Max Power—Kw @ r/min – 309/2200
Max Torque—N.m @ r/min – 1750/1300-1400
HP – 420
Cylinder – 6 Inline
Water Cooled – Yes
Direct Injection – Yes
Engine driven P.T.O – No
Displacement (l) – 11.596
Compression Ratio – 17:01
Service – Dual circuit air brakes
Emergency / Parking – Spring potential brake
Auxiliary – ABS & EVB
Size and ply rating – 315x80R22.5 incl spare wheel
Type – VR4/01D-7.5
Suspension – Non-free standing stabilization leaf spring, hydraulic shock absorber, transverse stabilizer
Type – HD7/016DGS – HL7/015DS-13/4.796
Suspension – Stabilizator suspension, 13 pcs leaf
spring (each 20mm). Hub reduction axles
Alternator – 55Amp
Starter Motor – 5.58kW
Batteries – 2 x 12V – 120AH
Gradeability @ GVM – 24% @ GVM
Max Geared Road Speed – 105km/h (Limited to 80km/h)
Final Drive Ratio – 4.769
Make / Type / Size – GFX 430mm single
Operation – Single dry frictional disc, diaphragm spring, pulling type
New Vehicle – 3 years / 300 000km (SA only)
Make/Model – 12JS200TA + QH50
No of Gears – 12
Synchromesh or Constant Mesh – Synchromesh
P.T.O – Yes
Crawler
1st – 12.10
2nd – 9.41
3rd – 7.31
4th – 5.71
5th – 4.46
6th – 3.48
7th – 2.71
8th – 2.11
9th – 1.64
10th – 1.28
11th – 1.00
12th – 0.78
Reverse L – 11.56
Reverse H – 2.59
Overall Length (OL) – 6 935
Overall Width (OW) – 2 495
Overall Height (OH) – 3 160
Front Overhang (FOH) – 1 410
Rear Overhang (ROH) – 625
Wheel Base (WB) – 4 175
Bumper to Back of Cab (BBC) – 2 420
Cab to rear axle / unit (CA) – 3 165
Turning Radius (TR) – 8 500
Fuel Tank Capacity (FTC) – 400 LTR
Manufacturers Gross Vehicle Mass (GVM) – 26 000
Manufacturers Gross Combination Mass (GCM) – 65 000
Manufacturers Front Axle Mass (GA) – 7 500
Manufacturers Rear Axle Mass (GAU) – 26 000
Permissible Maximum Vehicle Mass (V) – 25 500
Permissible Maximum Front Axle Mass (AF) – 7 500
Permissible Maximum Rear Axle Mass (AR) – 18 000
Unladen Front Axle Mass (UF) – 4 700
Unladen Rear Axle Mass (UR) – 4 900
Total Unladen Mass (UT) – 9 600
Permissible Max Drawing Vehicle Mass (D/T) – 65 000
Hydraulic Tiltable Cab
