MAKE: WEICHAI

MODEL: WD10G220E23

EMISSION REGULATION: EURO 2

RATED POWER: 162 KW@2000 RPM

MAXIMUM TORQUE: 900 NM

DISPLACEMENT: 9.726L

CYLINDER: 6

WATER COOLED: YES

DIRECT INJECTION: YES

ASPIRATION: TURBOCHARGED & INTERCOOLED

RADIATOR: ENLARGED RADIATOR

SERVICE BRAKE: CALIPER DICS BRAKE / AIR OVER HYDRAULIC

PARKING BRAKE: FLEXIBLE SHAFT CONTROL / MECHANICAL

TYPE: 23.5-25 16PR TUBELESS

PATTERN LEVEL: L-3

DIFFERENTIAL FRONT TYPE: CONVENTIONAL

DIFFERENTIAL REAR TYPE: CONVENTIONAL

AXLE OSCILLATION: ±12°

BUCKET TYPE: ROCK BUCKET/COAL BUCKET

BUCKET SIZE: 3.3 CUBE

OPTIONAL BUCKETS AVAILABLE

BATTERIES: 2X12V-120AH MAINTENANCE FREE

STARTER MOTOR: 8.1KW

ALTERNATOR: 70 A

TYPE: ARTICULATED TYPE, FULL-HYDRAULIC POWER STEERING

STEERING RELIEF PRESSURE: 16 MPA

MAXIMUM TURNING RADIOS: 35°

AXLE OSCILLATION: ±12

THE CENTER OF OUTSIDE TIRE: 6626 MM

THE CENTER OF OUTSIDE BUCKET: 7200 MM

MAIN PUMP TYPE: GEAR

MAIN RELIEF PRESSURE: 18 MPA

LIFTING TIME: 5.5 S

CYCLE TIME: 10.5 S

PILOT CONTROL: YES

PLANETARY, POWER SHIFT

TORQUE CONVERTER: SIGNLE STAGE, FOUR ELEMENTS

TRANSMISSION: FIXED-SHAFT, MULTI-SPEED, ELECTRONIC CONTROLLED
HYDRAULIC TRANSMISSION

MAX. TRAVEL SPEED, FWD: 38 KM/H

MAX. TRAVEL SPEED, REV: 15 KM/H

NUMBER OF GEARS, FWD: 2

NUMBER OF GEARS, REV: 1

STATIC TIPPING LOAD (FULL TURN): 10000 KG

MAXIMUM LIFTING FORCE: 170 KN

MAXIMUM DUMP ANGLE AT FULL HEIGHT: 45°

DUMP CLEARANCE AT FULL HEIGHT DISCHARGE: 3050 MM

DUMP REACH AT FULL HEIGHT DISCHARGE: 1100 MM

MAXIMUM HINGE PIN HEIGHT: 4100 MM

MAXIMUM DIGGING DEPTH, BUCKET LEVEL: 40 MM

BUCKET ROLLBACK AT GROUND LEVEL: 45°

BUCKET ROLLBACK AT CARRY: 59°

BUCKET ROLLBACK AT MAXIMUM HEIGHT: 45°

ROPS&FOPS: OPTIONAL

A/C: OPTIONAL

ADJUSTABLE AIR SUSPENSION SEAT: YES

SEAT BELT: YES

STROBE LIGHT: YES

FIRE EXTINGUISHER: YES, SABS STANDARD

ENGINE OIL PRESSURE METER: YES
HYDRAULIC OIL TEMPERATURE METER: YES

COOLANT TEMPERATURE METER: YES

HOUR METER: YES

VOLTAGE METER: YES

OVERALL LENGTH: 8220 MM

OVERALL WIDTH: 3066 MM

OVERALL HEIGHT: 3450 MM

MIN. GROUND CLEARANCE: 440 MM

WHEEL BASE: 3250 MM

OPERATING WEIGHT: 16.4 TON

TURNING RADIUS (OUTSIDE OF TIRE): 6626 MM

TURNING RADIUS (OUTSIDE OF BUCKET): 7200 MM

WHEEL TREAD: 2238 MM

FUEL TANK: 300L

ENGINE OIL: 21L

HYDRAULIC TANK: 170L

TRANSMISSION AND TORQUE CON- VERTER: 45L

FRONT AXLE: 29X2L

REAR AXLE: 29X2L

COOLING SYSTEM: 65KG
