Model – Weichai WP7H
Type – High pressure common rail, turbocharged
No. of cylinder – 6
Emission – Tier 3 / Stage III
Displacement – 6.8L
Power output – 140kW/2000rpm
Type – Axial variable plunger pump
Max. discharge flow – 2x270L/min
Bucket – 137/148kN
Arm – 99/107kN
Type – Backhoe bucket
Capacity – 045-1.2(1.1) m3
Width – 1342mm
Type – Axial variable plunger motor
Track roller – 2×8
Carrier roller – 2×2
Track shoe – 2×47
Travel speed – 3.3/5.3km/h
Max. Drawbar pull – 212kN
Gradeability – 70% (35°)
Swing motor type – Swash plate plunger motor
Swing speed – 0-11.0r/min
Brake type – Pressure release mechanical braking
Fuel tank – 405L
Cooling system – 30L
Engine oil – 25L
Hydraulic oil tank – 190L
System Capacity – 400L
Shoe width – 600mm
Ground pressure – 47.7kPa
Operating weight – 21900kg
Max. digging height – 10100
Max. dumping height – 7190
Max. digging depth – 6490
Max. vertical digging depth – 5770
Max. depth cut for 2500mm level bottom – 6295
Max. digging distance – 9865
Max. digging radius at ground level – 9680
Min. swing radius of work equipment – 2970
Overall length – 9605
Ground contact length (Transportation) – 4915
Overall height (to top of boom) – 3040
Overall width – 2980
Overall height (to top of cab) – 3105
Counter weight ground clearance – 1120
Ground clearance – 470
Tail swing radius – 2905
Tread – 3460
Track length – 4270
Track gauge – 2380
Track width – 2980
Shoe width – 600
Bonnet height – 2400
Revolving frame width – 2725
Distance from swivel center to tail – 2920
